Description
- Module Properties: non-isolated constant voltage module
- Rectification: non-synchronous rectification
- Input voltage: 4.5V-35V
- Output Voltage (Less than input): 1.3V-30V
- Output current: 3A maximum
- Conversion efficiency: 92% (maximum)
- Switching frequency: 150KHz
- Output ripple: 50mV (maximum) 20M-bandwidth
- Load regulation: ± 0.5%
- Voltage regulation: ± 2.5%
- Operating temperature: -40 ℃ to +85 ℃
